Garmin Hunter Advanced Package - Includes Alpha 200 & T20 Collar
These bundles are not to be separated and only at Mansfield Hunting and Fishing
High country mountain tops to rocky ridges — no matter where you hunt, you and your dogs need reliable gear.
ALPHA 200
| Dimension |
2.70 x 6.40 x 1.30″ (6.80 x 16.20 x 3.40 cm) *dimensions do not include antenna |
| Weight |
9.90 oz (280 g) with standard antenna and battery |
| Water rating |
IPX7 |
| Touchscreen |
Yes |
| Display Type |
Transflective, colour TFT touchscreen |
| Display Size |
1.80″ W x 3.0″ H (4.70 x 7.70 cm); 3.50″ diag (88.90 mm) |
| Display Resolution |
282 x 470 pixels |
| Battery type |
rechargeable lithium-ion (included) |
| Battery life |
Up to 20 hours |
| Memory/History |
16 GB |
| Interface |
High-speed USB |
| Maps & Memory |
| Preloaded maps |
Yes (TopoActive) |
| Ability to add maps |
Yes |
| Basemap |
Yes |
| Automatic routing (turn by turn routing on roads) for outdoor activities |
Yes (with optional mapping for detailed roads) |
| Satellite Imagery |
Yes, direct to device (no annual subscription required) |
| External memory storage |
microSD™ card (not included) |
| Waypoints/favorites/locations |
10,000 |
| Tracks |
Up to 20 assets (any combination of compatible dog devices and handhelds) |
| Navigation Track Log |
20,000 points, 200 saved gpx tracks, 300 saved fit activities |
| Navigation Routes |
250 |
| Stored contacts |
250 dogs |
| Group management |
Yes |
| Sensors |
| GPS |
Yes |
| Galileo |
Yes |
| Barometric altimeter |
Yes |
| Compass |
Yes (tilt-compensated 3-axis) |
| High-sensitivity receiver |
Yes |
| Daily Smart Features |
| Compatible with Garmin Messenger app |
Yes |
| Safety and Tracking Features |
| LiveTrack |
Yes |
| Tactical Features |
| XERO™ Locations |
Yes |
| Outdoor Recreation |
| Point-to-point navigation |
Yes |
| Area calculation |
Yes |
| FISH FORECAST |
Yes |
| Sun and moon information |
Yes |
| Custom maps compatible |
Yes |
| Radio Features |
| Frequency band |
VHF |
| Channels |
5 |
| Range |
T 5, 14.50 kilometres; T 5 mini, 14.50 kilometres |
| Location reporting (send and receive GPS positions) |
Yes |
| Vibration alert |
Yes |
| Contacts |
Yes |
| Outdoor Applications |
| Compatible with Garmin Explore™ app |
Yes |
| Garmin Explore website compatible |
Yes |
| Dog tracking |
Yes |
| Connections |
| Connections Wireless Connectivity |
Yes (Wi-Fi®, Bluetooth® and ANT+®) |
T20 Collar
| Dimension |
8.1 x 4.5 x 3.5 cm (3.2″ x 1.8″ x 1.4″) |
| Weight |
168.5 g (5.9 oz) for transmitter and antenna (without collar)
239.5 g (8.4 oz) total weight (with collar) |
| Water rating |
1 ATM (10 metres) |
| Battery type |
Rechargeable lithium-ion pack; user-replaceable |
| Battery life |
Standard battery pack (included)
- Up to 68 hours using dynamic update rate (default mode)
- Up to 25 hours with 2.5 second update rate
- Up to 84 hours with 2 minute update rate
Extended battery pack (sold separately)
- Up to 136 hours using dynamic update rate (default mode)
- Up to 50 hours with 2.5 second update rate
- Up to 168 hours with 2 minute update rate
|
| Interface |
USB-C |
| Sensors |
| GPS |
Yes |
| Galileo |
Yes |
| Device frequency |
VHF |
| High-sensitivity receiver |
Yes |
| Dog Tracking Features |
| Tracking range |
Up to 14.5 km |
| LED beacon lights: |
Yes (multiple colour options) |
| Sleep mode |
Yes (Alpha products only) |
| Rescue mode: |
Yes |
| Dog Training Features |
| Vibration |
Not available in U.S.; may be available in other regions |
| Tone |
Not available in U.S.; may be available in other regions |
| Collar compatibility |
Up to 1″ (2.54 cm) |
| Stereo features |
| Software updates |
Wi-Fi® technology (when charging and connected to network) |
