Description
A revolutionary rangefinder above the rest. See your target through premium glass with a high-resolution graphic overlay that displays distance, mapping, navigation and more for an immersive visual experience.
FULL-COLOUR, HIGH-RESOLUTION GRAPHIC DISPLAY OVERLAY
RAZOR-SHARP OPTICS WITH 7X MAGNIFICATION, 32 MM OBJECTIVE LENS AND EDGE-TO-EDGE CLARITY
RANGE TREES OUT TO 1,800 METERS AND ANIMALS OUT TO 1,375 METERS — RANGE EVEN FARTHER WITH THE SENSOR LOCATE FEATURE
USE THE LASER LOCATE™ FEATURE TO DROP A GPS WAYPOINT ON OBJECTS YOU’VE RANGED
USE VISUAL RECALL TO RELOCATE AN OBJECT YOU’VE RANGED AND USE THE MAP TO NAVIGATE TO IT
| Dimension | 125.41 mm x 89.66 mm x 50.59 mm (4.94″ x 3.53″ x 1.99″) |
|---|---|
| Weight | No battery: 362.88g (0.80 lbs) With battery: 385.1g (0.849 lbs) |
| Water rating | IPX7 |
| Display Type | Multi-colour digital light projection |
| Display Size | 32 mm (1.2″) diagonal |
| Display Resolution | 960 x 540 pixels |
| Battery type | 2 AAA lithium batteries (included) |
| Battery life | 1,400 ranges (1 sec range, 10 sec display) |
| Multi-colour display | |
| Operating range | -20° C to 60° C (-4° F to 140° F) |
| Memory/History | 32 GB internal less file system space |
| Interface | USB-C |
| Laser classification | Class 1 |
Daily Smart Features |
|
| Connectivity | Bluetooth® |
|---|---|
| Mobile app | Explore App |
Xero laser range finder features |
|
| Magnification | 7x |
|---|---|
| Objective | 32 mm |
| Field of view | 7 degrees |
| Field of View (linear feet at 914 meters) | 365 ft |
| Eye relief | 18 mm (0.71″) |
| Exit pupil diameter | 4.6 mm |
| Focus adjustment | +/- 4 diopters |
| Compass | |
| Barometer | |
| Precision | +/- .1 m |
| Accuracy | +/- .25 m out to 1000 m +/- 1.0 m beyond 1000 m |
| Distance to deer targets (full sun) | Animals, 1,375 m; Trees, 1,800 m; Retro Reflective, 5,000 m |
| Distance to targets (night) | Animals, 2,775 m; Trees, 3,600 m; Highly reflective, 5,100 m; Retro reflective, 7,000 m |
| Laser Locate | |
| Sensor locate | |
| Onboard mapping | |
| Visual recall | |
| APPLIED BALLISTICS SOLVER | Onboard, unlockable via AB Synapse app |
| Xero archery ballistics | |
| Angle compensated distance | |
| GARMIN SHARE | |
| Stores locations, tracks and courses | |
| Measures distances between 2 points | |
| Area calculation | |
| Compatible with Garmin Explore App | |
| Carrying case | Yes (included) |
| Laser beam divergence | 0.5 x 0.5 mrad |
Security Information |
|
| Security updates until at least (YYYY-MM-DD) | 2027-10-17 |
|---|---|
| EU Data Act Information – Range Finders | |
