Description
Experience the unparalleled power and innovation of the HIKMICRO HABROK 4K HE25L. Engineered with precision for daytime use, it integrates a cutting-edge 256px thermal detector and an advanced 4K digital detector, all behind a 5.5x-22x @60mm lens. With a built-in 1000m laser rangefinder, this versatile binocular is your ultimate companion for activities like forest & field hunting, birding, animal tracking, adventure, and rescue missions, delivering top performance in any weather conditions.
4K DIGITAL SENSOR
The Habrok 4k HE25L comes with an impressive 4k day/night sensor allowing for extremely long target identification with crystal clear imagery.
THERMAL & NIGHT VISION
The combination of thermal and night vision on one device allows the user to have quick detection and fast recognition with the press of a button.
LASER RANGE FINDER
The inclusion of a 1000m Laser Range Finder gives the user the knowledge of target distance at all times.
| Image Sensor | VOx Uncooled Focal Plane Arrays | ||||
| Max. Resolution | 256 × 192 | ||||
| Frame Rate | 50 Hz | ||||
| Pixel Interval | 12 μm | ||||
| Response Waveband | 8 μm to 14 μm | ||||
| NETD | Less than 35 mK (@25°C), F# = 1.0 | ||||
| Lens (Focal Length) | 25 mm, F1.0 | ||||
| Focus Mode | Focus Ring | ||||
| Detection Range | 1200m | ||||
| Min. Focusing Distance | 3m | ||||
| Magnification | 4.3x to 17.2x (4x) | ||||
| Field of View(H × V), Degrees/m @100m | 7.0° × 5.3°/12.2 m × 9.3 m | ||||
| Optical Module | |||||
| Image Sensor | 1.88'' Progressive Scan CMOS | ||||
| Max. Resolution | 3840 × 2160 | ||||
| Focal Length | 60 mm, F2.2 | ||||
| Min. Working Distance | 8m | ||||
| Focus Mode | Focus Ring | ||||
| Magnification | 5.5x to 22.0x (4x) | ||||
| Field of View (H × V), Degrees/m @100 m | 6.9°× 4.1°/12.0 m × 7.2 m | ||||
| Smart IR | Yes | ||||
| IR Illuminator Wavelength | 850 nm | ||||
| Viewing Range at Night | 400 m | ||||
| Image Display | |||||
| Display | 0.49 inch, OLED, 1920 ×1080 | ||||
| Palettes | Thermal: Black Hot, White Hot, Red Hot, Fusion; Optical: Day, Night, Auto | ||||
| FFC (Flat Field Correction) Mode | Auto, Manual, External Correction | ||||
| Exit Pupil | 8 mm | ||||
| Eye Relief | 15 mm | ||||
| Diopter (Range) | -5 D to +3 D | ||||
| Brightness Adjustment | Yes | ||||
| Tone Adjustment | Cold, warm | ||||
| Contrast Adjustment | Yes | ||||
| Zoom Pro | Yes | ||||
| System | |||||
| Record Video | Yes | ||||
| Capture Snapshot | Yes | ||||
| Audio Recording | Yes | ||||
| Standby Mode | Yes | ||||
| Storage | Built-in EMMC (64 GB) | ||||
| PIP | Yes | ||||
| Hotspot | Yes | ||||
| Hot Track | Yes | ||||
| Digital Magnetic Compas | Yes | ||||
| GPS | Yes | ||||
| Local Album | Yes | ||||
| Power Supply | |||||
| Battery Type | Replaceable and Rechargeable Li-ion Battery | ||||
| Battery Operating Time | ≥ 8 h (25℃, with hotspot off) | ||||
| Type-C Power Supply | 5 VDC, 2 A Supports External Power Supply | ||||
| General | |||||
| Protection Level | IP67 | ||||
| Dimension | 138 mm × 68.2 mm × 223 mm (5.4" × 2.7" × 8.6") | ||||
| Working Temperature | -30℃ to +55℃ | ||||
| Weight | 795g without batteries | ||||
| Interpupillary Adjustment Range | 60 mm to 74 mm | ||||
| Mounting Adapter | 1/4“-20-UNC | ||||
| Laser Rangefinder | |||||
| Safety Class for Laser | Class 1 | ||||
| Wavelength | 905 nm | ||||
| Max. Measuring Range | 1000 m | ||||
| Measurement Accuracy | ±1 m | ||||
| Min. Measuring Range | 10 m |
