Description
The new Thermion stands out from the crowd primarily with its excellent HD image quality and powerful sensor capabilities. It’s perfect for long-distance shooters and for observation with a wide field of view. The HD sensor resolution maintains optimal image quality even at high zoom levels. With the help of new advanced image processing algorithms, Thermion 2 LRF XL50 offers great opportunities for long-range observation in diverse weather conditions. Thermion 2 LRF XL50 – the new premium standard.
NEW TOP OF THE RANGE SENSOR
The Pulsar Thermion 2 LRF XL50 Thermal Scope offers the highest level of thermal imaging. The image generated with the new 1024×768- pixel thermal sensor features high definition and rich detail ideal for uncompromised trophy identification. The silhouettes, anatomy & behavioural peculiarities of the animal are clearly visible and easily distinguished.
BALLISTIC CALCULATOR
Thermion 2 LRF ensures accurate shooting at any distance. The built-in laser rangefinder provides the hunter with an exact sense of distance to the target while the sophisticated internal ballistics algorithm calculates the suggested POA for accurate long-range shooting
LASER RANGE FINDING
Understanding the target distance is an essential factor in making the right decisions. The compact laser rangefinder with a range of up to 800 metres is seamlessly integrated into a slim design riflescope, the receiver and emitter are within clearance limits of a single optical channel.
| Sensor | 1024x768 @ 12 µm (NETD <35 mK) |
| Objective lens | F50 / 1.0 |
| Magnification, x | 1.75 – 14 |
| Field of view (HxV), degrees / m@100m | 14x10.5 / 24.6x18.4 |
| Detection range, m | 2300 |
| Sensor | |
| Type | uncooled |
| Resolution, pixels | 1024x768 |
| Pixel pitch, µm | 12 |
| NETD, mK | 35 |
| Frame rate, Hz | 50 |
| Optics | |
| Objective lens | F50 / 1.0 |
| Magnification, x | 1.75 – 14 |
| Field of view (HxV), degrees / m @ 100 m | 14x10.5 / 24.6x18.4 |
| Eye relief, mm | 50 |
| Display | |
| Type | AMOLED |
| Resolution, pixels | 1024x768 |
| Range Performance | |
| Detection range, m | 2300 |
| Laser Rangefinder | |
| Safety class for laser equipment according to IEC 60825-1:2014 | 1 |
| Wavelength, nm | 905 |
| Max. measuring range, m | 800 |
| Measurement accuracy, m | ± 1 |
| Reticle | |
| Click value, H/V, mm at 100 m | 24 – 1.75х, 12 – 3.5х, 6 – 7х, 3 – 14х |
| Click range, H/V, mm at 100 m | 4800 / 4800 |
| Number of preloaded reticles | 10 |
| Video Recorder | |
| Video / photo resolution, pixel | 1024x768 |
| Video / photo format | .mp4 / .jpg |
| Built-in memory, GB | 64 |
| Wi-Fi | |
| Wireless Protocol | Wi-Fi |
| Wireless Standard | IEEE 802.11 b/g/n/ac (WPA) |
| Frequency, GHz | 2.4 / 5 |
| Bluetooth | |
| Wireless Protocol | BLE 4.2 |
| Wireless Standard | IEEE 802.15.1 |
| Frequency, GHz | 2.4 |
| Environmental Characteristics | |
| Degree of protection, IP code (IEC60529) | IPХ7 (waterproof) |
| Operating temperature range, °С | -25 – +50 |
| Connections and Compatibilities | |
| Max. recoil power on rifled weapon (Eo), Joules | 6000 |
| Shock resistance on the smooth-bore rifles, caliber | 12 |
| Compatible mounts | Standard 30 mm rings |
| Supported Application | Stream Vision 2, Stream Vision Ballistics |
| Power Supply | |
| Output voltage, V | 3.0 – 4.2 |
| Battery type | Dual Li-Ion B-Pack Mini Power System: 2 A·h Changeable Battery (external) / 4.9 A·h Battery (internal) |
| Capacity, mAh | 2000 (external) + 4900 (internal) |
| Operating time on battery pack (at t=22°C), h * | 7 |
| External power supply, V | 5V, 9V (USB Type-C Power Delivery) |
| Weight & Size | |
| Body material | Aluminum alloy |
| Dimensions, mm | 426x78.5x94.5 |
| Weight, kg | 1.03 |
